High Definition P4 LED Module Display Waterproof Cabinet With 1200 W/Sq.M Consumption

Brand Name : JC

Model Number : JC-IFC-P4

Certification : CE/ ROHS/ISO,FCC,UL

Place of Origin : Shenzhen Guangdong China

MOQ : 1 Square Meter

Price : Negotiation

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 10000 Square Meter Per Month

Delivery Time : 8-10 working days days after advance payment arrived.

Packaging Details : Wooden case/Flight case/Carton

Application : Adervertising

Brightness : 2000cd/sqm

Color : Full-color

LED chip : Epistar

Warranty : 2 Years

Module size : 256x128mm

Life span : 100000hours

Contact Now

High Definition P4 LED Module Display Waterproof Cabinet With 1200 W/Sq.M Consumption

Asynchronous Ultra Color P4 Led Screen Cabinet 512x512x75mm 2000cd/sqm SMD2121 Black MBI5024IC

1. The unit price depends on the quantity, we can offer you at a competitive price.

2. Your inquiry related to our products or prices will be replied in 24hrs.

3. Well-trained and experienced staffs to answer all your enquires in fluent English.

4. Distributorship are offered for your unique design and some our current models.

5. Protection of your sales area, ideas of design and all your private information.

Before we offer you best quotation, we'd like to confirm some details if you don't mind:

1. What's the size of screen, cabinet you prefer?

2. What's the best viewing distance with your project?

3. What's the color of cabinet you need? Any logo on back of cabinet?

4. When do you need to get goods? Is this urgent?

5. Any special requests? Such as video processor,hanging bar,flight case for package? Please advise it as well.

Adventages

1. The cabinet made of aluminum, has very light weight, would not deformation, easy to transport. In addition, it is convenient to assemble and disassemble.

2. Has high refresh, Meet the needs of high-definition video shooting

3. Equips professional video processor, which supports signal formats like AV, DP, VGA, DVI, YPBPR, HDMI, SDI etc

4. Supports brightness adjustment and white balance custom adjustment with 256 levels, which enables mix usage of different batches of display.

5. Bring brilliance brilliant visual experience

Specification

Pixel Pitch	4mm
Module Size	256x128mm
Module Resolution(Pixel)	64dots ×32dots
Pixel Density	62500 dots
LED Type	SMD 3 in 1
Pixel Configuration	1R1G1B
Wavelength (R.G.B)	R:625±2nm G:525±2nm B:470±2nm
Drive Mode	Dynamic 1/16 Duty Constant Current
Cabinet Size	512x512x70mm
Cabinet Resolution	128x128dots
Brightness	≥ 2000cd
Contrast	≥2000:1
Viewing Angle	140°(Horizontal )/140°(Vertical )
Minimum Viewing Distance	3m
Grey Scale	10bits/1024levels
Color Capability	16,777,216
Color Temperature	5000-9300K
Average Power consumption	400W
Working Voltage	AC 220V/110V s±15% 50-60 HZ
Frame Frequency	60-85HZ
Refresh Frequency	240-1000HZ
Brightness Correction	Pixel, Module, Cabinet Correction
Operating Temperature	Static:-40°C~+85°C Working:-20°C~+60°C
Operating Humidity	10-90% RH
LED Lifespan	100,000 hours
MTBF	≥50,000 hours
Computer Operation System	Win 98/ Win XP/ Win 2000
Video Signal Input	RF,S-Video,RGB,RGBHV,YUV,YC,VGA, DVI, HDMI, SDI,HD-SDI ,Composite
Video Signal Output	RF, S-Video, GB, RGBHV, YUV, YC etc.
Graphics Card	DVI Graphics Card
Control Distance	UTP CAT5E:100m Multi-mode Fiber:500m Single-mode Fiber:10km
Control System	LINSN OR DB-STAR
Software	LED studio 10.0
Waterproof Level	IP43
Installation	Wall mount, hung and stand structure
Out of Control Rate	0.01%

Installation Process

High Definition P4 LED Module Display Waterproof Cabinet With 1200 W/Sq.M Consumption

Certifications

FAQ

1. How can i place an order?
Please provide the details of your requirements as clear as possible. So we can send you the offer at the first time. For designing or further discussion, it is better to contact us with Skype/email /phone, in case of any delays.
2. What kind of display we provide?
We have indoor/outdoor/led curtain/mobile LED /rental LED display /LED stage/LED Dance Floor/Irregular LED display for you choose.
3. What about the lead time for order?
Always: 3-20 days, as your order quantity, sometimes we have stock, can delivery within 5 days
4.How about the warranty ?
We have two years warranty.
